Aster
A trace-driven cache hierarchy simulator in Rust
Aster is a trace-driven cache hierarchy simulator I wrote in Rust to test replacement-policy and prefetcher ideas outside the constraints of ChampSim’s C++ codebase. It reads ChampSim-format memory traces and models a full L1I / L1D / L2 / LLC hierarchy including dirty bits, writeback propagation, and per-level geometry with the replacement policy and prefetcher selected from a TOML config.
Replacement Policy and Prefetcher Implementation
All replacement policies and prefetchers are exposed as trait implementations, making adding new configurations plug and play. Specific policy settings are exposed through the TOML configuration file.
A PC-keyed Stream-buffer Prefetcher
Beyond the cache itself, Aster models a stream-buffer prefetcher keyed on PC, with configurable degree and stream count, so prefetching and replacement can be measured together rather than in isolation.
Validation
Aster is validated against ChampSim on identical traces and geometry, matching its demand-miss stream to within 0.02% at every cache level across a streaming scan (libquantum) and a pointer-chasing workload that thrashes the LLC (mcf). Full methodology and the per-level comparison are in the README.
What It Doesn’t Do
Aster has no timing model, so it measures miss behavior rather than cycles or IPC; single-core and single-thread; no MSHRs, so it doesn’t capture miss-level parallelism or merging. Two replacement policies (LRU, SRRIP) and one prefetcher are implemented so far, with DRRIP and SHiP on the roadmap.
Sample Output
=== Aster Simulator ===
trace: traces/429.mcf-217B.champsimtrace.trace.gz
warmup insts: 1000000
sim insts: 20000000
--- cache config ---
L1I block_size=64 cache_size=32768 assoc=4 policy=srrip prefetcher=none
----------------------------
L1D block_size=64 cache_size=32768 assoc=8 policy=srrip prefetcher=none
----------------------------
L2 block_size=64 cache_size=524288 assoc=8 policy=srrip prefetcher=stream_buffer
prefetch_settings: degree=4, num_streams=10
----------------------------
LLC block_size=64 cache_size=2097152 assoc=16 policy=srrip prefetcher=none
repl_settings: increment=3, insertion_rrpv=1, max_rrpv=8
----------------------------
heartbeat: 21000000/21000000 insts (100.0%) elapsed= 13.0s
=== Results ===
wall time: 13.01s
Instructions simulated: 20000000
L1I: hits=19999999 misses=1 hit_rate=100.0% MPKI=0.00 writebacks=0 writebacks_received=0 prefetch_hits=0 prefetch_unused=0
prefetch_issued=0 prefetch_redundant=0
L1D: hits=8622098 misses=1327273 hit_rate=86.7% MPKI=66.36 writebacks=37373 writebacks_received=0 prefetch_hits=0 prefetch_unused=0
prefetch_issued=0 prefetch_redundant=0
L2: hits=784118 misses=543156 hit_rate=59.1% MPKI=27.16 writebacks=30358 writebacks_received=37373 prefetch_hits=775159 prefetch_unused=204
prefetch_issued=775363 prefetch_redundant=2320909
LLC: hits=1350 misses=541806 hit_rate=0.2% MPKI=27.09 writebacks=29543 writebacks_received=30358 prefetch_hits=0 prefetch_unused=759653
prefetch_issued=0 prefetch_redundant=0
